[product profile] C-Power10B is a mono dual-color compatible with 7 color control card which is launched by the Shenzhen Lumen Electronics Co., Ltd.!
C-Power10B card has rich applications, gorgeous results; a very high performance and price ratio and strong market competitiveness!
C-Power10B card has the same external call protocol and secondary development interface as C-Power full range of products!
[product functional specification] control area (single, double color) | 1024* 64 pixels; 7 colors without gray-scale | SC | The standard board contains 8 megabytes (64Mbit) of which the program space is 3.2 megabytes. | Support programme content | Support video programs for Flash (SWF), animation (GIF), pictures, text, clock, temperature and other types of programs 60 kinds of action special effects, snow, mosaic, fan spread and so on; Each window independently set around the borders of the language programs, text can be transparent superposition of multiple windows to display multi-program mode, the maximum on the screen can store thousands of programs menu program hierarchical management, Edit management simple and quick support program broadcast by time, accurate to the week, hour, minute | |
|
|
|
|
|
Windowing mode | Each program supports a maximum of 10 playing windows for arbitrary segmentation, and each window supports simultaneous playback of content in different formats | Subsidiary function | The board has its own real-time clock RTC management and setup. Environment data programs such as analog clock, digital clock, transparent display, support temperature Support brightness sensor (achive automatic adjustment of 32 level brightness) | On-board optional font | 2MB font and system space Optional loading 16 × 16, 24 × 24, 32 × 32, 40 × 40, 48 × 48, 56 × 56, etc. (Chinese simplified, traditional Chinese, Japanese, Korean, etc.) Font library, which can be edited by the customer; supports a font library with up to 8 different fonts built in and displayed at the same time Support for Hong Kong supplementary character fonts, Hindi | Standard software | LED Control Center (LedCenterM V5.3.7) | communication mode | TCP/IP port: network communication WIFI version: integration of all versions of WIFI RS232/RS485 high-speed serial port : baud rate reach to 115200 maximum | |
|
|
|
Infrared remote Control and Keyboard selection | Support infrared remote control and key board broadcast program, function control | Plug-in communication accessories support | Support a variety of external wireless communication modes: ZigBee module, RF wireless module, etc. | else | Provide rich secondary development interface and interface manual, provide secondary development demo program and source code | joggle | With 4 HUB12 interfaces（2 HUB08 interfaces）,2 HUB75 interfaces |
?? ??
|
